Environmental Honeycomb Sandwich Wall Panels

The paper honeycomb sandwich panel product is composed of two layers of formed metal panels (or other material panels) and a polymer insulated inner core which is directly foamed and matured in the middle of the panel. The paper honeycomb sandwich panel is widely used in large industrial plants, warehouses, stadiums, supermarkets, hospitals, cold storage, mobile homes, building plus layers, clean workshops and places where insulation and fire protection are required.

Color:
Thickness:
Width:
Quantity:
  • 8mm/16mm/32mm
  • YUMI

1. Paper honeycomb sandwich panel introduction:

533


The paper honeycomb sandwich panel product is composed of two layers of formed metal panels (or other material panels: aluminum plate, steel plate,etc.  ) and a polymer insulated inner core (honeycomb core) which is directly foamed and matured in the middle of the panel. The paper honeycomb sandwich panel is widely used in large industrial plants, warehouses, stadiums, supermarkets, hospitals, cold storage, mobile homes, building plus layers, clean workshops and places where insulation and fire protection are required.


2. Paper honeycomb sandwich panel performance:


The paper honeycomb sandwich panel is often inserted into the tongue-and-groove type. It has the advantages of convenient installation, time saving, material saving, good flatness and high strength, and is especially suitable for ceiling and partition systems. 2, thickness (mm): 50-250; 3, length (mm): due to continuous molding production, the length of the board can be determined according to user needs; 4, width (mm): 1150 (1200) 5, core material performance: A, Polystyrene bulk density: ≥15kg/m3 Thermal conductivity ≤0.036W/mK Maximum operating temperature: about 100 oC B, rock wool bulk density: ≥110kg/m3 Thermal conductivity: ≤0.043W/mK Maximum operating temperature: about 500 oC A.


3. Paper honeycomb sandwich panel advantages:

  • colorful: various colors as per RAL, normal colors: sea blue, grey white, white.

  • durable,

  • light weight,

  • heat/sound insulated, anticorrosion,

  • anti flaming

  • recycling: can be reused to save costs,

  • anti oxidation: anti corrosion, shock proof, dust proof.

  • surface: bright, smooth,



4. Honeycomb sandwich panels Specifications:

Application Propor wall sandwich panels
Type 950/1150
Steel sheets thickness(mm) 0.326-0.6
Paper Honeycomb hole distance(mm) 8/16/32
Effected width for panel(mm) 950/1150
Paper Honeycomb thickness(mm) 50/75/100
Length Max 5.8m for 20GP container
Max 11.8m for 40GP container
Color Regular color:Sea blue/Beige/Red
Special color:As per RAL color swatch or Customized
