Essential Design Principles for Steel Composite Beams

1. Types of Composite Beams

A composite beam is a load-bearing member constructed from steel plates or structural steel sections through welding. This member can be subjected to compression, tension, or bending.

Commonly used composite beams include I-beams and box beams (rectangular and trapezoidal).

2. Design of Composite Beams

Designing composite beams requires calculating their strength, stiffness, and stability. All three must meet the specifications. Stability includes overall stability and local stability.

Strength is the ability of a member to withstand external forces without failure.

Stiffness is the ability of a member to resist elastic deformation under external forces.

Stability is the ability of a member to maintain stability under external forces.

Brightness section characteristics include cross-sectional area, moment of inertia, and flexural modulus.

3. Stiffening Ribs of Composite Beams

The stiffening ribs of a composite beam consist of transverse stiffening ribs, longitudinal stiffening ribs, and short stiffening ribs.

The overall stability of a box-section composite beam is ensured by its height-to-width ratio; the height-to-width ratio should not exceed 3.

The overall stability of H-beams or I-beam composite beams is ensured by their length-to-width ratio.

The local stability of the composite beam web is ensured by its height-to-thickness ratio.

The local stability of the compression flange of an I-beam is ensured by the ratio of its free overhang width to its thickness.

The local stability of the compression flange of a box girder is ensured by the ratio of its width to its thickness.
