Application :
1. The high-end demand for temporary construction products at construction sites, such as the office of the project manager, accommodation, meeting rooms, etc.;
2. Due to site restrictions, the construction site can only install container-type modular housing products;
3. Housing for field operations, such as mobile office and dormitory for field exploration and construction;
4. Emergency rooms, such as military mobile command center, rescue mobile command center, disaster relief mobile command center, etc.
The overall hanging series houses are highly adaptable to the environment, easy to install on site, and can be used for temporary office, accommodation, integrated kitchen, bathroom and other purposes for medium and high-end requirements.
Advantage :
1. Mobility: removable and reusable.
2. Quick set-up: short manufacturing period and no foundation.
3. Safety: steel frame structure, windproof and shockproof.
4. Durability: The outer wall of the steel plate is corrosion-resistant, acid-resistant, does not rust or crack, and the service life is more than 20 years.
5. Sound insulation and heat insulation: It adopts air cut-off design, which has good sound insulation and heat insulation.
6. Aesthetics: It can be designed in various shapes, the outer wall has many colors, and the appearance is bright and beautiful.
7. Low cost, low cost, high quality and low price.
8. Strong load-bearing capacity, can be stacked together for use.
Specification
Container House Size | |||||||
Size | External Dimensions | Internal Dimensions | Weight | ||||
Length | Width | Height | Length | Width | Height | ||
8'X8' | 2435mm | 2435mm | 2896mm | 2235mm | 2235mm | 2625mm | 950kg |
10'X8' | 3025mm | 2435mm | 2896mm | 2825mm | 2235mm | 2625mm | 1150kg |
16*X8' | 4885mm | 2435mm | 2896mm | 4685mm | 2235mm | 2625mm | 1350kg |
20 ’X8‘ (Standard Model) | 6055mm | 2435mm | 2896mm | 5855mm | 2235mm | 2625mm | 1800kg |
24'X8 | 7200mm | 2435mm | 2896mm | 7000mm | 2235mm | 2625mm | 2300kg |
30X8 | 9000mm | 2435mm | 2896mm | 8800mm | 2235mm | 2625mm | 2450kg |
20'XI0' | 6055mm | 3000mm | 2896mm | 5855mm | 2800mm | 2625mm | 2380kg |
Remark: Also available external height of 3300mm individual packing height:648mm. |
Packing & Delivery:
☆ Packing:
The maximum loading is 15 sets for standard size in a shipping container.
☆ Delivery:
Delivery time for regular colors,coating types and thickness: 7-10 days ;
Delivery time for special colors,coating types and thickness: 15-25 days ;
Delivery term: FOB/CIF/CFR/DDP is available;
We can find good forwarder for customer or accept appointed forwarder from customers.
